Yxlon: New climate chambers for development and production

Responding to the growing demand for CT metrology applications, Yxlon has invested in four additional climate chambers in Hamburg, Germany. Two chambers are dedicated to R&D for new and ongoing technology development; the other two are part of production, where the FF20/35 CT metrology systems are fine-tuned for accuracy.

Computed tomography is a technology capable of properly measuring and analyzing even internal structures of parts. Hundreds of high-resolution X-ray images taken from all angles are used to reconstruct a three-dimensional CT volume, which can then be visualized and edited with suitable software. Modern X-ray technology and sophisticated detectors can scan down to micro- and even nanometer scales. This makes them well-suited for the requirements of electronics manufacturing and new production technologies such as 3D printing.

With their granite base, quality manipulation unit, temperature-controlled cabinet, and the stable focal spot of their micro- and nanofocus tubes, Yxlon CT metrology systems are perfectly equipped for these tasks. However, any material will react not only to vibrations, but also temperature changes, so it is vital for metrological applications to keep the ambient temperature stable. The Yxlon climate chambers maintain a temperature of 20°C +/- 1°C, both stabilizing the test objects stored in the room before inspection and preventing temperature fluctuations within the inspection cabinet when the loading door is opened before and after scans. They therefore qualify as class 3 measuring rooms according to VDI/VDE 2627.
