More Efficient Quality Control Through Measurement Software


With the product information (PMI) integrated in the CAD data, measurement programmes can be created automatically. With the revised release, separate or combined tolerance zones are recognised and the corresponding evaluation is created automatically. If defective geometry elements are attached to a PMI in the CAD model, the revised release automatically creates the inspection characteristic without measuring element and generates an inspection plan. The user can then analyse possible indications in the work log. For more clarity, the inspection characteristic groups are automatically generated and thus inspection characteristic groups are formed from the "CAD views" of the CAD systems Calypso.

Relevant optics functions for metrology

The revised version of Zeiss Calypso 2022 supports Zeiss O-Detect. This means that inspection plans from other CMMs - especially from the Zeiss O-Inspect - can also be run on this device. Users of Zeiss O-Detect have access to all reporting evaluations and Calypso functions. The optical distortion correction feature for increasing the accuracy of optical systems increases the optical distortion correction. The use of small magnifications increases the "Field of View". At the same time, more geometric elements can be captured in the image. Depending on the measuring task and the required tolerance, the necessary number of measuring images is reduced and measuring time is saved at the same time.
