Twisted nanoscale semi­conductors manipulate light in a new way, researchers at the University of Bath and the University of Michigan have shown. The effect could be harnessed to accelerate the discovery and development of life-saving medicines as well as photonic techno­logies. Specifically, the photonic effect could help enable rapid development and screening of new antibiotics and other drugs through automation – essentially, robotic chemists. It offers a new analysis tool for high-throughput screening, a method to analyze vast libraries of chemical compounds.

A tiny sample of each compound fills a well on a microplate. The wells can be as small as a cubic milli­meter, and a plate the size of a chocolate bar can contain a thousand of them. “To meet the requirements of the emerging robotized chemistry, wells are getting really tiny – too small for current analytical methods,” said Ventsislav Valev, professor of physics at the University of Bath. “So, funda­mentally new methods are needed to analyze would-be drugs.”

One of the key measure­ments in drug analysis is chirality, or which way the molecule twists. Biological systems, including the human body, typically prefer one direction over the other, a right-handed or left-handed curl. At best, a drug molecule with the wrong twist does nothing, but at worst, it can cause harm. The effect discovered by the researchers allows chirality to be measured in volumes that are 10,000 times smaller than a cubic millimeter.

“The small volumes possible for regis­tration of these effects are the game changing property that enables the researchers to use very small amounts of expensive drugs and collect thousands times more data,” said Nicholas Kotov, Professor of Chemical Sciences and Engineering at the University of Michigan. The method relies on a structure inspired by biological designs, developed in Kotov’s lab. Cadmium telluride, a semi­conductor commonly used in solar cells, is shaped into nanoparticles resembling short segments of twisted ribbon. These assemble into helices, mimicking the way proteins assemble.

“Being illu­minated with red light, the small semi­conductor helices generate new light that is blue and twisted. The blue light is also emitted in a specific direction, which makes it easy to collect and analyze,” Kotov said. “The trifecta of unusual optical effects drastically reduces the noise that other nanoscale molecules and particles in biological fluids may cause.” To use these effects in high-throughput screening for drug discovery, the nano­particles assembling into helices may be mixed with a drug candidate. When the nanohelices form a lock-and-key structure with the drug, simulating the drug target, the twist of the nanohlices will change drama­tically. This change in the twist can be measured through the blue light.

“Applications to drugs are now only a question of techno­logical development. Our next step is to seek funding for this development,” said Valev, who led the photonic experiments at Bath. The generation of the blue light from red is also helpful in drug development in samples approaching the complexity of biological tissues. The separation of two colors of light is techni­cally easy and helps reduce light noise, false positives and false negatives. While the team attempted experiments testing the bio­logical concept, COVID-19 closures and delays caused the protein samples to spoil each time. The University of Michigan has filed for patent protection and is seeking partners to bring the new techno­logy to market. (Source: U. Mich)

Reference: L. Ohnoutek et al.: Third-harmonic Mie scattering from semiconductor nanohelices, Nat. Phot., online 13 January 2022, DOI: 10.1038/s41566-021-00916-6

Links: Centre for Photonics and Photonic Materials, University of Bath, Bath, UK • Biointerfaces Institute, University of Michigan, Ann Arbor, USA

Further reading: Twisting to the light of nanoparticles, Wiley Industry News, 24 September 2021
