Researchers have created a photo­acoustic imaging endoscope probe that can fit inside a medical needle with an inner diameter of just 0.6 millimeters. Photo­acoustic imaging, which combines light and sound to create 3D images, can provide important clinical information, but until now the instru­ments have been either too bulky or too slow for practical use as forward-viewing endo­scopes.

“Traditional light-based endo­scopes can only resolve tissue anatomical information on the surface and tend to have large footprints,” said Wenfeng Xia from the King’s College London School of Biomedical Engineering & Imaging Sciences. “Our new thin endoscope can resolve subcellular-scale tissue structural and molecular information in 3D in real-time and is small enough to be integrated with inter­ventional medical devices that would allow clinicians to charac­terize tissue during a procedure.” The ultra-thin endoscope was developed through a close colla­boration between King’s College London and University College London. It consists of two optical fibers each roughly the diameter of a human hair.

“The imaging speed of this photo­acoustic endo­microscopy probe is two orders of magnitude higher than those previously reported,” said Xia. “It could eventually allow 3D charac­terization of tissue during various minimally invasive procedures such as tumor biopsies. This could help clinicians pinpoint the right area to sample, which would increase the diagnosis accuracy.”

Photoacoustic imaging works by shining pulses of light onto absorbing structures in the body such as red blood cells or DNA. The structures then generate acoustic waves that can be detected by ultra­sound sensors and used to form images that can resolve molecular, structural and functional information from below the tissue surface. Although fiber-based photo­acoustic endoscopy probes have been developed, they usually require a bulky ultrasound detector or have a low imaging speed. In the new work, the researchers overcame both of these challenges by combining wavefront-based beam shaping with light-based ultra­sound detection and a fast algorithm for controlling the device. This unique combination allowed them to create an extremely small probe without sacrificing imaging speed.

The new probe uses two thin optical fibers – one for delivering the pulsed light used to generate the photo­acoustic waves and the other for ultrasound detection. For the excitation light, a high-speed digital micro­mirror device is used to scan a tightly focused light spot. This device has nearly one million tiny mirrors that can be indepen­dently flipped at tens of thousands of frames per second to change the wavefront of the light so that it can be focused and scanned quickly. For the ultrasound detection, the researchers developed an optical micro­resonator that could be fabricated on the tip of an optical fiber. When sound waves hit the micro­resonator, its thickness changes, which, in turn, modifies the amount of light that is reflected back into the fiber, allowing optical detection of the acoustic waves.

To demons­trate the new device, the researchers used it to acquire high-resolution images of mouse red blood cells covering an area 100 microns in diameter. “We were able to accomplish this at about 3 frames per second,” said Xia. “We also showed that the needle probe can be scanned to signi­ficantly enlarge the field-of-view in real-time by stitching together consecutive images.” The researchers point out that imaging performance was not sub­stantially degraded when the probe was scanned, suggesting that it isn’t affected by modest fiber bending.

However, as a step toward clinical use, they will further investigate how complex fiber bending or semi-rigid confi­gurations affect imaging performance. They also say that artificial intelli­gence could be used to increase the imaging speed. “Although this work focused on the development of a photo­acoustic endo­microscopy probe, the high-speed method used to deliver the excitation light can be used to incor­porate other imaging modalities such as fluorescence imaging, Raman micro­scopy and two-photon microscopy,” said Xia. (Source: Optica)

Reference: T. Zhao et al.: Ultrathin, high-speed, all-optical photoacoustic endomicroscopy probe for guiding minimally invasive surgery, Biomed. Opt. Exp. 13, 4414 (2022); DOI: 10.1364/BOE.463057
