Ultrashort infrared light pulses are the key to a wide range of technological applications. The oscillating infrared light field can excite molecules in a sample to vibrate at specific frequencies, or drive ultrafast electric currents in semi­conductors. Anyone intending to exploit the oscillating waveform of ultrashort light pulses, to drive cutting-edge electro-optical processes for example, faces the same question – how to best control the waveform themselves. The generation of ultrashort pulses with adjustable waveforms has been demons­trated in different wavelength ranges like the UV-visible and the near-infrared. Physicists from the attoworld team at the Munich University LMU, the Max Planck Institute of Quantum Optics (MPQ) and the Hungarian Center for Molecular Finger­printing (CMF) have now succeeded in generating ultrashort mid-infrared pulses and precisely controlling their electric-field waveforms. With this infrared waveform mani­pulator at hand, new possi­bilities of optical control for biomedical appli­cations and quantum electronics come into reach.

The basis for the new mid-infrared source is a stabilized laser system that generates light pulses with a precisely defined waveform at near-infrared wavelengths. The pulses consist of only one oscillation of the light wave and are thus only a few femto­seconds long. When these pulses are sent into a suitable nonlinear crystal, the generation of long-wave­length infrared pulses can be induced by taking advantage of complex frequency-mixing processes. In this way, the team succeeded in producing light pulses with an excep­tionally large spectral coverage of more than three optical octaves, from 1 to 12 micrometres. The researchers were not only able to understand and simulate the underlying physics of the mixing processes, but also developed a new approach to precisely control the oscilla­tions of the generated mid-infrared light via the tuning of the laser input para­meters.

The resulting adjustable waveforms can, for example, selectively trigger certain electronic processes in solids, which could allow to achieve much higher elec­tronic signal processing speeds in future. “On this basis, one could envision the development of light-controlled electronics,” explains Philipp Stein­leitner. “If opto-electronic devices were to operate at frequencies of the generated light, you could speed up today's electronics by at least a factor of 1000.”

The attoworld physicists are paying particular attention to the use of the new light techno­logy for the spectro­scopy of molecules. When mid-infrared light passes through a sample liquid, for example human blood, molecules in the sample begin to oscillate and in turn emit charac­teristic light waves. Detecting the molecular response provides a unique fingerprint that depends on the exact composition of the sample. “With our laser technology, we have signi­ficantly expanded the controllable wavelength range in the infrared,” says Nathalie Nagl. “The additional wave­lengths give us the opportunity to analyze even more precisely how a mixture of molecules is composed,” she continues.

In the attoworld group, colleagues from the Broadband Infrared Diagnostics (BIRD) team led by Mihaela Zigman and the CMF Research team led by Alexander Weigel are parti­cularly interested in measuring the precise infrared molecular finger­prints of human blood samples. The vision is to identify charac­teristic signatures that allow to diagnose diseases like cancer. A developing tumor, for example, leads to small and highly complex changes in the molecular composition of the blood. The goal is to detect these changes, and to enable the early diagnosis of diseases by measuring the infrared finger­print of a simple drop of human blood. “In the future, our laser techno­logy will allow our colleagues to detect previously undetec­table changes in specific biomolecules such as proteins or lipids. It thus increases the relia­bility of future medical diagnostics using infrared laser techno­logy,” says Maciej Kowalczyk. (Source: LMU)

Reference: P. Steinleitner et al.: Single-cycle infrared waveform control, Nat. Phot., online 20 May 2022; DOI: 10.1038/s41566-022-01001-2

Link: Attoworld team, Ludwig-Maximilians-Universität München & Max-Planck-Institute for Quantum Optics, Munich & Garching, German
